SS3001 Slide Route Switch

SS3001 Slide Route Switch

  • Series:SS3001
  • Format:See the following profile
  • Specifications

    Switch model: SS3001 series
    Name:

    SS3001 Slide Route Switch

    Main Specifications: Travel: 29.7mm;
    Rated power: DC 6V 0.3A;
    Operating torque: 250±150gf.cm;
    Operating temperature: -16℃~ 60℃;
    Operating life: 5,000 Min;
    Product Features:

    Slide route switch with clear sense of clicks;

    Applications:

    Amplifiers, instrument or other electronic products;

    The main functions are volume adjustment, function switching,

    band adjustment, etc.

    SS3001 Product Specifications

    ONE、MECHANICAL CHARACTERISTIC
    1. Operating Force: 250gf.cm±150gf.cm
    2. Function: 2P12T

    TWO、ELECTRICAL CHARACTERISTIC
    1. Rated power: DC 6V 0.3A
    2. Contact Resistance: 100MΩ Max.
    3. Insulation Resistance: 100 MΩ 1 Min at DC 500V
    4. Dielectric Voltage: 1 Minute at AC 500V

    THREE、ENDURANCE CHARACTERISTIC
    1. Operating Life: 5,000 Min

    Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".
